Automation, the application of machines to tasks once performed by human beings or, increasingly, to tasks that would otherwise be impossible. Although the term mechanization is often used to refer to the simple replacement of human labour by machines, automation generally implies the integration of machines into a self-governing system. Automation has revolutionized those areas in which it has been introduced, and there is scarcely an aspect of modern life that has been unaffected by it.
The term automation was coined in the automobile industry about 1946 to describe the increased use of automatic devices and controls in mechanized production lines. The origin of the word is attributed to D.S. Harder, an engineering manager at the Ford Motor Company at the time. The term is used widely in a manufacturing context, but it is also applied outside manufacturing in connection with a variety of systems in which there is a significant substitution of mechanical, electrical, or computerized action for human effort and intelligence.
In general usage, automation can be defined as a technology concerned with performing a process by means of programmed commands combined with automatic feedback control to ensure proper execution of the instructions. The resulting system is capable of operating without human intervention. The development of this technology has become increasingly dependent on the use of computers and computer-related technologies. Consequently, automated systems have become increasingly sophisticated and complex. Advanced systems represent a level of capability and performance that surpass in many ways the abilities of humans to accomplish the same activities.
Automation technology has matured to a point where a number of other technologies have developed from it and have achieved a recognition and status of their own. Robotics is one of these technologies; it is a specialized branch of automation in which the automated machine possesses certain anthropomorphic, or humanlike, characteristics. The most typical humanlike characteristic of a modern industrial robot is its powered mechanical arm. The robot’s arm can be programmed to move through a sequence of motions to perform useful tasks, such as loading and unloading parts at a production machine or making a sequence of spot-welds on the sheet-metal parts of an automobile body during assembly. As these examples suggest, industrial robots are typically used to replace human workers in factory operations.
This article covers the fundamentals of automation, including its historical development, principles and theory of operation, applications in manufacturing and in some of the services and industries important in daily life, and impact on the individual as well as society in general. The article also reviews the development and technology of robotics as a significant topic within automation. Historical Development Of Automation
The technology of automation has evolved from the related field of mechanization, which had its beginnings in the Industrial Revolution. Mechanization refers to the replacement of human (or animal) power with mechanical power of some form. The driving force behind mechanization has been humankind’s propensity to create tools and mechanical devices. Some of the important historical developments in mechanization and automation leading to modern automated systems are described here.
Early developments
The first tools made of stone represented prehistoric man’s attempts to direct his own physical strength under the control of human intelligence. Thousands of years were undoubtedly required for the development of simple mechanical devices and machines such as the wheel, the lever, and the pulley, by which the power of human muscle could be magnified. The next extension was the development of powered machines that did not require human strength to operate. Examples of these machines include waterwheels, windmills, and simple steam-driven devices. More than 2,000 years ago the Chinese developed trip-hammers powered by flowing water and waterwheels. The early Greeks experimented with simple reaction motors powered by steam. The mechanical clock, representing a rather complex assembly with its own built-in power source (a weight), was developed about 1335 in Europe. Windmills, with mechanisms for automatically turning the sails, were developed during the Middle Ages in Europe and the Middle East. The steam engine represented a major advance in the development of powered machines and marked the beginning of the Industrial Revolution. During the two centuries since the introduction of the Watt steam engine, powered engines and machines have been devised that obtain their energy from steam, electricity, and chemical, mechanical, and nuclear sources.
Each new development in the history of powered machines has brought with it an increased requirement for control devices to harness the power of the machine. The earliest steam engines required a person to open and close the valves, first to admit steam into the piston chamber and then to exhaust it. Later a slide valve mechanism was devised to automatically accomplish these functions. The only need of the human operator was then to regulate the amount of steam that controlled the engine’s speed and power. This requirement for human attention in the operation of the steam engine was eliminated by the flying-ball governor. Invented by James Watt in England, this device consisted of a weighted ball on a hinged arm, mechanically coupled to the output shaft of the engine. As the rotational speed of the shaft increased, centrifugal force caused the weighted ball to be moved outward. This motion controlled a valve that reduced the steam being fed to the engine, thus slowing the engine. The flying-ball governor remains an elegant early example of a negative feedback control system, in which the increasing output of the system is used to decrease the activity of the system.
Negative feedback is widely used as a means of automatic control to achieve a constant operating level for a system. A common example of a feedback control system is the thermostat used in modern buildings to control room temperature. In this device, a decrease in room temperature causes an electrical switch to close, thus turning on the heating unit. As room temperature rises, the switch opens and the heat supply is turned off. The thermostat can be set to turn on the heating unit at any particular set point.
Another important development in the history of automation was the Jacquard loom (see photograph), which demonstrated the concept of a programmable machine. About 1801 the French inventor Joseph-Marie Jacquard devised an automatic loom capable of producing complex patterns in textiles by controlling the motions of many shuttles of different coloured threads. The selection of the different patterns was determined by a program contained in steel cards in which holes were punched. These cards were the ancestors of the paper cards and tapes that control modern automatic machines. The concept of programming a machine was further developed later in the 19th century when Charles Babbage, an English mathematician, proposed a complex, mechanical “analytical engine” that could perform arithmetic and data processing. Although Babbage was never able to complete it, this device was the precursor of the modern digital computer. See computers, history of.
Jacquard loom, engraving, 1874At the top of the machine is a stack of punched cards that would be fed into the loom to control the weaving pattern. This method of automatically issuing machine instructions was employed by computers well into the 20th century.
